CHH458PBK, 45 Series Palm Case Electronic Enclosure, Black, Recessed, PP3 Battery Compartment, Size 3 - 165x82.5x26
Handheld Electronics Enclosure for industrial, IoT, diagnostic and healthcare electronic devices
- Moulded in UL94-5VA Flame Retardant ABS
- Lid mounted by four self-tapping screws
- Removable end panel for ease of access and ideal for machining
- ABS end panel version as standard, infra-red end panel version to order
- Sliding battery compartment lid options for AA or 9V PP3 batteries
- Plain / no battery compartment version available to order
- Textured lid versions for consistent all over surface finish
- Smooth recess lid version for membrane keypads or overlays
- PCB pillars moulded in lid and base, screws available to order
- 45 series has been designed to meet the requirements of IP54
| External Length (mm) | 165 |
| External Width (mm) | 82.5 |
| External Height (mm) | 26 |
| Internal Length (mm) | 88 |
| Internal Width (mm) | 72 |
| Internal Height (mm) | 20 |
| Weight (G) | 121 |
| Base Material | Plastic |
| Material Type | ABS UL94-5VA |
| Colour | Black |
| UL Rating | UL94-5VA |
| IK Rating | N/A |
| IP Rating | IP54 |
| Special Features | Battery Compartment |
| Operating Temperature | 85 Deg C |
| Brand | CamdenBoss |
| Battery Door | Yes |
| Battery Compartment Type | PP3 |
| Development Board | N/A |
CNC Milling
Machining of holes, vents, pockets and cut-outs
Engraving
Engrave an enclosure with your own design or logo
Shielding
Internal RFI coatings provide your enclosure with additional protection
Custom Painting
Coat your enclosure with a custom colour to match your brand
Digital Printing
Print in full colour directly onto the surface of your enclosure
Systems Integration
Box build and product testing service available
